Struck: 4500 l. Heaped: 6000 l.
Diesel Perkins 1104 C-44 TA Turbo water-cooled, 4 cylinders. Maximum power 80 kW. (107 HP), set at 2300 r.p.m.
Fully hydrostatic Hydromatic Rexrorth with electric inverter. Gear box with mechanic control., two speeds, 4 wheel drive.
Dana Hurth with oil bath disc brakes and planetary reducers. Front axle steering and swinging. Rear axle fixed.
|Speed||Working speed from 0 to 12 km/h, road transfer from 0 to 25 km/h.|
Reversible seat with automatic inversion of hydraulic steering circuits. ROPS-ROPS cab closed on 3 sides.
|Bucket||Heavy duty rock type. Hydraulic tilting with 2 cylinders.|
Steel profile specially engineered for off-road operations.
|Hydraulic system||2 independent circuits, variable outlet pump for hydrostatic transmission and hydraulic pump for services. Heat exchanger water-oil-air/air type.|
|Brakes||Oil bath disc brakes on 4 wheels. Hydraulic parking brake negative on rear axle manually operated.|
|Tyres||Offroad industrial type 16/70-20 14 PR.|
|Steering||Hydrostatic "Load sensing". Radius internal mm. 2900, external mm. 5800|
|Electric System||12 Volt.. 120 Ah battery for electric start and road lighting. Safety battery cutoff.|
|Gradient||Fully loaded 30%.|
|Tanks||Diesel 115 l Hydraulic oil 80 l.|
|Weight||Empty Kg. 5800.|
Machine equipped with checking and block valves for maximum safety of the operator
|Catalogues||The machine is equipped with Use and Maintenance and Spare Parts Manuals according to CE regulations.|
