| Mixing Unit |
Drum Capacity 7.600 liters. Concrete output: 5,5 m3 per batch. Double mixing screws, cover for emergency unloading. Drum rotation by hydraulic motor and planetary reducers. Mixing and discharging speed independent from r.p.m. of diesel engine.
Discharging by reversing drum. |
| Engine |
Cummins Turbo – Diesel B5.9 TAA, water – cooler, 6 cylinders.
Maximum power 112 kW. (150 HP). Engine mounted transversal on the rear.Perkins 1106D – E66TA Turbo-Diesel, water-cooled, 6 cylinders. Maximum power 117 kW. (157 HP). Engine mounted transversal on the rear. |
| Transmission |
Hydrostatic. Pump and motor are connected to the differentials through a
2 speed reducer (working and transfer). 4 wheel driving and steering. |
| Speed |
Working speed from 0 to 10 km/h, road transfer from 0 to 30 km/h. |
| Driving Seat |
Front cab on side of loading shovel ROPS-FOPS type complete with double closing door. |
| Chassis |
Steel profile specially engineered for off-road operations. |
| Hydraulic system |
Three circuits. 2 variable outlet pumps for hydrostatic transmission and drum rotation. 2 gear pumps for services. Inlet and outlet filter. Heat exchanger water/ oil-air-air-type. |
| Joymix |
All hydraulic functions of shovel controlled by a single – fully servo controlled Joystick lever. |
| Loading Shovel |
Capacity 600liters. Complete with hydraulic opening gate. |
| Chute |
Hydraulic slewing and hydraulic tilting controlled by the cab. |
| Catalogue |
The machine is equipped with Use and Maintenance and Spare Parts Manuals according to CE regulations. |
| Weighing |
Electronic System. “Load Cells” acting on the drum, display and printer in the cab. (on request) |
| Water System |
Self-contained. Hydraulic driven water pump, water meter.
High pressure water pump. |
| Gradient |
Fully loaded 30°. |
| Brakes |
Oil bath disc brakes inside differential axles. Twin independent circuits. Negative hydraulic parking brake. |
| Tyres |
Off road industrial type 18-19,5 PR 16. |
| Steering |
Hydrostatic. 3 way steering, 4 wheel steering self-lining. Radius: Internal mm.1800 – external mm. 4000 |
| Electric System |
12 volt. 120 Ah battery for electric starter and road lighting. Safety battery cut-off. |
| Tanks |
Water: 2x600 liters. Diesel: 150 liters. Hydraulic oil: 120 liters. |
| Weight |
About Kg. 8600. Equally distributed on both axles. |
| Safety |
Machine equipped with checking and block valves for maximum safety of the operator. |
| Catalogue |
The machine is equipped with Use and Maintenance and Spare Parts Manuals according to CE regulations. |
