carmix 2.5
carmix 2.5carmix 2.5


Mixing Unit Concrete mixer: drum capacity 3.450 liters (759 gal UK – 911 gal US). Concrete output: 2,5 m3 per batch. EN 206-1 SLUMP S1 class, yield no vibrated. Double mixing screws, cover for emergency unloading. Mixing and discharging speed indipendent from r.p.m. of diesel engine. Discharging by reversing drum.
Engine Perkins 1104D-44T Turbo-Diesel, water cooled, 4 cylinders. Power KW 62,5 (84 HP) set at 2200 rpm.
Transmission Hydrostatic Bosch-Rexroth. Heavy duty differential axles with planetary reducers. Front axle swinging and steering. Rear axle fixed.
Axles Dana Spicer with oil bath disc brakes and planetary reducers.
Speed Working speed from 0 to 10 km/h (0 – 6,21 mph), road transfer from 0 to 24 km/h (0 – 14,91 mph). Electric servo control.
Driving Seat ROPS-FOPS canopy. Reversible seat with automatic inversion of hydraulic steering circuit.
Chassis Steel profile specially engineered for off-road operations.
Hydraulic system The hydraulic concrete mixer system is composed by 3 indipendent circuits. 2 variable outlet pumps for hydrostatic transmission and drum rotation. 1 pump for services. Inlet and outlet fi lter. Heat exchanger water/oil-air type.
Loading Shovel Effective capacity per load 400 liters, complete with hydraulic opening gate.
Chute Slewing and hydraulically tilting.
Water System Self-contained. Hydraulic driven water pump, water meter, washing outlet.
Gradient Fully loaded 30°.
Brakes Oil bath disc brakes inside differential axles. Twin indipendent circuits. Negative hydraulic parking brake.
Tyres Off road industrial tyre 12.5-20 PR 12.
Steering Hydrostatic “load sensing”. Radius: internal mm. 2550, external mm. 5100.
Electric System 12 Volt. 120 Ah battery for electric starter and road lighting. Safety battery cut-off.
Tanks Water: 2 x 275 liters (2 x 60 gal UK – 2 x 72 gal US). Diesel: 100 liters (22 gal UK – 26 gal US). Hydraulic oil: 70 liters (15 gal UK – 19 gal US).
Weight In running order Kg. 5.300 (11.648 lb) equally distributed on both axles.
Safety Machine equipped with checking and block valves for maximum safety of the operator.
Catalogue The machine is equipped with Use and Maintenance and Spare Parts Manuals according to CE regulations.
